A Trusted UK Supplier Of ESD Control Products Since 1986

Vinyl Floor Matting

2-layer, durable, vinyl floor matting manufactured with a dissipative surface and conductive backing. This floor mat is excellent to use for electronics manufacturing applications. Complies to DIN EN 61340­5­1 standards. Material is 2mm thick and maximum roll size is 1500mm wide and 10 metres long.

Out of Stock – replacement item BFM10

£9,999.00 excl. VAT

Out of stock

Description

Durable, 2­-layer, static-dissipative, grey fleck vinyl floor matting with a conductive backing.

Please note: This product is now out-of-stock, please see our alternative replacement item BFM10.

Vinyl floor matting is suitable to use for electronics manufacturing applications that require the use of ESD footwear. The material is 2mm thick and the maximum roll size is 1500mm wide and 10 metres long. The smooth surface allows for easy cleaning. The matting can be re-used again and again.

The material is abrasion-resistant and is suitable for chair castors. Installation is very simple and can be secured with double-sided tape. The matting complies to DIN EN 61340­5­1 standards. The product is also certified for RoHS and REACH regulations.

Key Features:

  • Two layer vinyl flooring.
  • Grey fleck in colour.
  • Static dissipative surface.
  • Conductive backing.
  • Maximum roll size is 1500mm wide and 10 metres long.
  • Complies with DIN EN 61340-5-1 standards.
  • RoHS and REACH compliant.
  • Insulation resistance according to DIN VDE 0100-410 (personnel safety).
  • Abrasion resistant.
  • Suitable for chair castors, depending on floor substrate.
  • Elastic.
  • Reusable.

Matting Options:

KSFM10: Full roll. 1500mm wide x 10 metres long.

KSMF Vinyl Floor Matting Bondline

To view our full range of ESD floor matting, click here.

Additional information

Weight N/A
Select a product:

KSFM10 – Vinyl Full Roll – 1.5m x 10m

Cleaning and Maintenance

Cleaning after installation:

1) Sweep the floor with ESD dustpan and broom.
2) Clean the floor with a wet mop with a mild alkaline solution (I.E. floor stripper, KS40GAL)
3) For machine cleaning, use red pads or medium hard brushes.
4) Make sure that no water or dirt remains on the floor.

Polishing after installation:

1) Use an ESD floor polish to polish the floor.

Daily maintenance:

Clean the floor with a wet mop using a high-quality floor cleaner having neutral or mild alkaline properties and follow the instructions. For high traffic areas, use an ESD floor polish where necessary.

Stain removal:

Remove all stains immediately to avoid permanent marks on the floor.

Warning: Stain removers may damage the floor. When in doubt, try the stain remover one small hidden area. Use the chemical rather than mechanical means to remove persistent stains.

View our full range of ESD cleaning products by clicking here.

Bespoke Flooring

We provide a premium service of bespoke custom sizing for our floor matting to suit all customer requirements. If you would like bespoke customisation, please make an enquiry to us.

Simon cutting ESD mat Bondline   Rounding Mat Corners Resize   Mat Studding Process Bondline  Stud in ESD Mat Bondline

Benefits of Using Bondline For Your ESD Flooring Installation

  • Over 30 years’ experience of installing ESD flooring.
  • Advice on floor preparation and most appropriate material to use.
  • Variety of materials to choose.
  • Complete supply, deliver and install package
    Installation by our recommended fitters with experience of floor installations.
  • Test Certification.
  • Annual testing/certification if required.

Bondline can provide installations of:

  • ESD Rubber / Vinyl Material.
  • ESD Static Dissipative Tiles.
  • Interlocking Tiles.
  • Vinyl Sheets.

When establishing an electrostatic protected area (EPA), making the correct choice of ESD flooring is essential to ensure that sensitive electronic components and assemblies are adequately protected from the harmful effects of electrostatic discharge (ESD).

Make an enquiry today about our bespoke flooring by contacting us.

Technical Datasheet & Materials

Technical Datasheet

Click here to view ‘Technical Datasheet’.

Materials

Click here for ESD matting guidance.

Click here to learn about the benefits of using ESD flooring for an Electrostatic Protected Area.
