ESD Workbenches (Square Tube Style) “Four Leg” Design

The Square Tube ESD Workbenches offer static-dissipative properties which act as protection from an electrostatic charge. These benches are suitable for use in the electronics assembly industry. Fully configurable to suit any application. Available with anti static Neostat or Lamstat worktops. Framework is powder-coated in a light grey. Includes wrist strap sockets. Manufactured in the UK. 5-day express delivery on specific configurations.

Contact us to discuss if you need a quick delivery ESD bench solution.

an icon of a lightning bolt

Product Code: fou/wor/ben

Clear

£9,999.00

This product is unavailable for online purchase. Please fill out this form and a member of our team will be in touch to discuss the product with you.

Description

Get 5-day express delivery on specific configurations with our ESD Square Tube Style Workbench

Our range of high-quality Square Tube ESD Anti Static Benches offers static dissipative properties which acts as protection from an electrostatic charge. These benches are perfect for use in the electrical and electronic assembly industries. This bench range has four legs with a leg in each corner to provide firm support. As standard, the ESD bench includes wrist strap sockets for attaching a wrist strap, which ensures that the user is Earthed to the bench (wrist straps sold separately).  Full range of accessories available including galvanised louvre panels, anti-static floor mat, ESD seating and circuit breaker. Manufactured in the United Kingdom.

Key Features of ESD Square Tube Style Workbench:

  • Quick lead times: 5-day express delivery* on specific configurations
  • Suitable for use as an assembly or repair bench in the electrical and electronic industries
  • Four legs – A leg in each corner gives firm support to the workbench
  • Sturdy powder-coated light grey framework
  • Full range of accessories available including galvanised louvre panels, anti-static floor mat, ESD seating and circuit breaker
  • Standard height available is 840mm (760mm and 920mm heights also available)
  • Delivered in knock-down form for easy on-site self-assembly
  • Anti Static Neostat or Lamstat worktop options available
  • Workshop bench weight load: 250KG evenly distributed
  • Designed in the UK by a proud workbench manufacturer
  • Fully configurable to suit any application
  • RoHS and REACH compliant and CE approved
  • Compliant according to IEC-61340-5-1 International Standard
Made in the UK logo UK Manufactured

Choice of Worktops Available:

  • Neostat Worktop – Total top thickness 20mm – A synthetic based sheet material
  • Lamstat Worktop – Total top thickness 20mm with chipboard core – Actual Lamstat thickness is 8mm

ESD Standards & Regulations Met:

ESD safe label - Bondline IEC-61340-5-1 European Conformity
bondline RoHS compliant bondline REACH compliant

Need a quick delivery ESD bench solution? Call us on +44 (0)1793 511000 to discuss options

Additional information

Select a product:

FOU/WOR/BEN – Square Tube Four Leg Style Workbench

Worktop Options

Neostat and lamstat worktops for ESD cantilever workbench from Bondline

Neostat Worktop

Description: A synthetic based sheet material for covering ESD workbenches Application: For general assembly, inspection and test applications where live equipment is not exposed Total Top Thickness: 20mm Material Properties: Highly resilient, heat, hot solder and flux resistant Leakage Resistance: 10 to the power of 6 - 10 to the power of 8 ohms Top Layer: Conductive Colours: Grey (other colour available on request - blue) Finish: Surface has a lightly embossed texture to eliminate glare Light Reflection: 29% Relevant Standards: BS EN 61340-5-1:2001 - Protection of Electric Devices from Electrostatic Phenomena

Lamstat Worktop

Total Top Thickness: 20mm with chipboard core Actual Lamstat Thickness: 8mm Leakage Resistance: 10 to the power of 6 - 10 to the power of 8 ohms conforming to BS IEC 61340-5-1 Material Properties: Resistance to heat, molten solder, oil pot test 20 minutes at 180 degrees and cigarette tests meets the requirements of EN438. Abrasion and scratch resistant Level 3 Class H to EN43. Chemical Resistance: Resistant to organic solvents, weak acids, alkaline, petrol and oil meets the requirements of EN438 Premium height adjustable ESD bench with laminate worktop - Bondline Electronics Ltd

Cleaning & Maintenance Instructions

1. Clean paint work periodically with warm soapy water. 2. Clean worktop surfaces periodically with warm soapy water or proprietary surface cleaners. Do not use solvents of any type. 3. Where cupboards and drawers are fitted, periodically oil hinges and locks sparingly with a light oil (3-in-1 or similar).

Technical Datasheet

ESD Square Tube Workbench: Technical Datasheet

Assembly Instructions

ESD Square Tube Style Bench: Assembly Instructions

Contact Us

Our sales and technical team are available to support you with any questions you may have regarding our products, services and more. To contact our team, please fill in the form below or click here.
icon of a box

Next Day UK Delivery

On selected products if ordered before 1pm

icon of users

Dedicated Account Manager

Dedicated account manager to help your ordering process

icon of a pound symbol

Competitive Prices

Great value on premium quality products

Project Management Guidance



Always make sure your floor, bench and chairs are in specification to the IEC-61340-5-1 International Standard and ESD safe.



Need guidance on setting up an ESD area? Contact us for help from one of our ESD experts, we can do this onsite or virtually. Call us on 01793 511000 or email sales@bondline.co.uk.
